Phased-out LED linear driver products

Xitanium 40W 0.35A 115V 230V

Order code: 929001402906

Full order code: 871869651548800

Popular downloads

View all downloads

Lighting Technology
LED

Line Frequency
50 to 60 Hz
Input Frequency
50 to 60 Hz
Total Harmonic Distortion IEC (Max)
15 %
Power Consumption
40 W
12V Output
No
Output Current Ripple (Max)
0.04 %
Maximum Efficiency at Full Load
85 %
Output Current (Max)
350 mA
Output Current (Nom)
350 mA
Output Current Tolerance (Max)
10 %
Earth Leakage Current (Max)
0.7 mA
Power Factor (Fraction)
0.9
Open Circuit Voltage (DC) (Max)
120 V
Input Current (Nom)
220 mA
Inrush Current Peak (Max)
16 A
Output Power (Max)
40 W
Output Power (Nom)
33.5 W
Default output current
350-350 mA
Inrush Current Width to 50% of Peak
202 µs
Energy Metering
No
Constant Current (CC)
True
Constant Voltage (CV)
False
Diagnostics
False
Output Power (Min)
27 W
Output Current (Min)
350 mA
Output Voltage (Max)
115 V
Output Voltage (Min)
80 V
Number of Products on MCB (16A Type B) (Max)
28
Protection class IEC
Safety class I
Surge Protection (Common/Differential)
EN61547 (L-L 1kV, L-G 2kV) kV
